Machine Specs
Used
Butfering Steelmaster Metal Grinding Machine
Key Specifications
Abrasive Belt Width
950 mm
Working Height
950 mm
Workpiece Thickness
0.5 – 120 mm
Abrasive Belt Width
970 mm
Abrasive Belt Length
1900 mm
First Drive (Abrasive Belt)
Abrasive Belt Drive
12.5/16 KW
Abrasive Belt Speed
9 / 18 m/sec
Diameter of Contact Roller
200 mm
Second Drive (7 Brushes)
Brush Drive (Brush Roller)
11 KW
Top Brush
11 KW
Brush Speed (Brush Roller)
15 m/sec
Top Brush Speed
6 m/sec
Diameter (Brush Roller)
200 mm
Top Brush Diameter
150 mm
Third Drive (7 Brushes)
Brush Drive (Brush Roller)
11 KW
Top Brush
11 KW
Brush Speed (Brush Roller)
15 m/sec
Top Brush Speed
6 m/sec
Diameter (Brush Roller)
200 mm
Top Brush Diameter
150 mm
Feed
Conveyor Belt Length
3300 mm
Width
950 mm
Feed Drive
Infinitely variable 1.5 KW
Height Adjustment
0.42 KW
Features
- Blowoff fan for drying workpieces
- Wet type debris/dust collection system with paper filtration
- PLC control
Electrical
Power
440 V / 3 phase
Footprint & Weight
Overall Dimensions (Approx.)
108″ F-B × 90″ L-R × 82″ H
Weight (Approx.)
8,000 lbs
